- SGS 24 Litre Direct Drive Air Compressor - 5.5 CFM 1.5 HP
SGS 24 Litre Direct Drive Air Compressor - 5.5 CFM 1.5 HP
3 monthly interest-free payments of £36.66. No hidden fees, 18+, terms apply. Learn more. | Air Displacement (CFM) | 5.5 |
| Brand | SGS |
| Cable Length (m) | 1.5 |
| Capacity | 24 |
| CFM Range | 5 to 10 CFM |
| Compressor Type | Portable |
| Corded | True |
| Corded/Cordless | Corded |
| Drive Type | Direct |
| EAN | 5055462745810 |
| Gross Weight (kg) | 23.00 |
| Lubrication Type | Oil-Lubricated |
| Max Flow (LPM) | 156.0 |
| Max Pressure Output (Bar) | 8.0 |
| Net Weight (kg) | 20.70 |
| No Load Speed (RPM) | 2800.0 |
| Operating Pressure (psi) | 116 PSI |
| Power | 1 |
| Power Phase | Single Phase |
| Power Source | Electric |
| Product Height (mm) | 535 |
| Product Length (mm) | 549 |
| Product Width (mm) | 240 |
| Sound Level (db) | 97.0 |
| Tank Size | 24 |
| Voltage (V) | 230 |
| Warranty | 2 Year Warranty |
SGS Air Compressor, equipped with a 24-litre receiver tank, is an excellent choice for both DIY enthusiasts and trade professionals. It’s perfect for tasks such as spray-painting, tyre inflation, nailing, and stapling. With a maximum working pressure of 8 bar, this compressor provides a reliable combination of performance, safety, and value for money.
Key Features
Powerful Motor: The compressor is powered by a 1.5 HP motor capable of delivering up to 5.5 CFM, ensuring efficient operation for various tasks.
Ideal Tank Size: The 24-litre tank is perfect for a range of applications including spraying, nailing, stapling, sanding, drilling, and cutting.
Easy Monitoring: Twin gauges allow for easy monitoring of both tank pressure and tool working pressure.
Quick Connections: It is equipped with euro quick-release connectors, making it easy to connect and disconnect air tools.
Ready to Use: The compressor is shipped with oil, but it may require additional oil before first use. It comes with a standard 13A UK plug for immediate setup.
Specifications
Engine Size: 1.5 HP
Power: 0.75 kW
Voltage: 230 V @ 50 Hz
Rated Speed: 2850 rpm
Air Displacement: 5.5 CFM
Sound Level: 97 dB
Current: 4A / 4.5A
Motor Poles: 2P
Discharge Pressure: 115 PSI / 8 bar
Tank Capacity: 24 litres
Air Outlet: 1/4" BSP to Euro Coupler (can be swapped for PCL fittings, check the Fitting & Couplers section)
Dimensions: 58 x 25.5 x 58 cm
Warranty: Covered by a 2-year extended warranty
Important Note
This compressor is intended for semi-professional use and is not recommended for commercial applications. For extensive use with impact wrenches, a compressor with a tank size of 50 litres or more is recommended.
Quality and Compliance
SGS is a British company with a full spares warranty and a dedicated service centre based at our East Midlands headquarters. Our air compressors are hand-built by expert engineers to the highest standards of quality and are European CE marked and German GS certified for product safety.
Safety Update
Due to changes in EU legislation, the safety valve rings have been removed by all manufacturers of air compressors. This change was made because the rings were being incorrectly used to vent the compressor, leading to undue wear. To vent the compressor, the air should be drained from the tank via the valve on the belly of the tank, which also helps to drain accumulated water.
Warranty:
2 Year Warranty
